Level Twelve

December 8th, 2010

Level Twelve is a teak and birds eye maple modernist-design computer system with hidden vent ducting and a separate self-powered USB peripheral system..



The Teak support box has its own power supply and connects a 2TB storage drive, optical drive and four front-mounted USB 3.0 ports via an internal USB 3.0 hub. The front mounted ports can recharge devices without the computer being turned on. The computer itself is located in the Birds Eye Maple box and is fully self-contained. It could be pulled out of the enclosure while it is operating.



The modified ventilation system consists of a large inlet duct located on the bottom of the Birds Eye Maple box. An industrial grade Delta cooling fan pulls hot air out of the top of the case and exhausts it out the back of the enclosure through a screened vent duct.



Specs:

Computer (Birds Eye Maple Box)
Intel Core i7-875K (Unlocked)
Gigabyte GA-H55N-USB3 Mini-ITX motherboard
Scythe Shuriken Rev. B HSF
8GB Crucial DDR1333 system memory
ATI 5750 1GB Low-profile video card
256GB Crucial C300 SSD
Antec 350W PSU
Delta FFB0912SH 90 CFM case fan

Support (Teak Box)
2TB Seagate 3.5" 6Gb/s hard drive with USB 3.0 interface
Plextor slimline USB DVD burner
4 front-mounted USB 3.0 ports
LS-PAB 60W power supply



















Construction Photos


























































A comprehensive project worklog of Level Twelve with over 200 photographs can be accessed at bit-tech.net, HardOCP or Overclockers Australia.

Thanks for looking.
