Project Ayr

February 8th, 2013

Ayr is a solid state, fanless, no-moving-parts, dead silent home theater PC.



The objective of this project was to get Intel HD4000 graphics out of a small, silent, and stylish computer design.

Aluminum chassis with an easily removable mahogany shell.



Features subtle lighting effects.

Specs:

Intel Core i3-3225 processor
Gigabyte Z77N-WiFi Mini-ITX motherboard
8GB DDR3 system memory
Intel Cherryville SSD
150W Pico-PSU
Silverstone HE02 passive heatsink
Microsoft Windows 8

Additional Photos:





An alternative version featuring a simple flat top.





















A comprehensive project worklog of Skyscraper with additional photos can be accessed at Jeffrey Stephenson Design Forum
